Ceramic double gate valve

Technical specifications

Product types

· Ceramic hard seal, parallel double gate.

· Flange structure,optional for clamp structure.

· Three-pieced valve body, self-cleaning design of gate plate

Pressure levels

· PN10,16，40,

· ASME Class 150,300

Caliber range

· DN50~300/2"~12"(full diameter)

· Diameter reduction is optiona

Usage temperature

· -29°C~200°C(Max,+500°C)

· -20°F~390°F(Max,+930°F)

Valve sealing grade

· IS0 5208 Grade D

· Zero leakage can be achieved according to customer requirements

Design Standards

· Valve Design and Manufacturing-ASME B16.34

· Valve Structure Length -Manufacturer's Standard,or as per customerrequirements

· Flange Connection Dimensions-GB/T9113,NE 1092-1.ASME B16.5

· Valve Inspection and Testing-GB/13927,JB/T9092,AP1598
