Fully lined ceramic ball valve

The fuly lined series of ceramic ball valves adopt high-performance structural ceramics (mainly including high-puritytoughened zirconia ceramics) as the valve core and lining material Therefore, in various extreme corrosive and weaerosion conditions such as strong acid, strong alkali, slag powder, particles, and slurry, etc, whether for cut-off olcontrol valve, the fully ined ceramic ball valves always have excellent and stable performance as well as longer servicelife than their traditional metal hard sealed ball valve counterparts.

The fully lined ceramic ball valve adopts a three-staged flange connection valve body with the pressure rating rangingfrom PN10 to PN150 ANSl Class150-900 and valve diameter range of DN15~DN300 (ANSI 1/2"-12"). Generally DN15-DN100 (1/2 "~ 4") ceramic ball valves adopt a floating ball structure, while DN125-DN300 (5"~12") ceramic ballvalves adopt a fixed ball structure. The ball uses the material of zirconia ceramic, while the seat and valve body liningmaterlals are ≥ 99% zirconia ceramic. As to other special materials, the structural lengths and flange connection dimensions can be customized according to customer requirements.
